2P/3P/4P/5P/6P7P/8P/10P flexible signal data transmission TRVVSP double screen twisted pair cable

Medium and high speed motion data transmission PVC cable can transmit analog and digital signals in devices with control processors, or as a connecting line between instruments and control equipment, it is suitable for occasions with low power consumption and uninterrupted data transmission. The twisted pairs and small pitch of the core wires can reduce external interference between the core wires.

Technical Parameter

Conductor twisting method:

Tinned copper conductor, fine copper wire twisting.

Conforms to DIN VDE0295 Class 6 and IEC 60228 Class 6.

Colored core identification

Outer sheath black (RAL 9005) matte

The core is twisted in layers with improved pitch

Improved tinned copper wire braided shielding

Technical data of TRVVSP double screen twisted pair cable:

Temperature range:

Mobile installation: -5℃ to +70℃

Fixed installation: -15℃ to +80℃

Minimum bending radius:

Mobile installation 7.5×cable diameter

Fixed installation 6×cable diameter

Service life for drag chain system:

More than 8 million cycles

Standard voltage:

Uo/U 300/300V

• High-flexibility PVC material for low-speed motion cables, double-twisted shielded, and data transmission cables.

• Conductors are twisted from 0.1mm fine copper wires, featuring a wrapped structure for flexibility and resistance to bending.

• Pairs of cores are twisted with varying pitches to facilitate signal transmission and prevent crosstalk interference.

• Equipped with a shield of tinned copper braid to eliminate interference.

• Primarily used for signal transmission in servo encoders, controllers, etc.

• Moderate oil resistance, with good abrasion resistance and high-low temperature performance.

• Under specified installation conditions, the service life can exceed 8 million cycles. Suitable for use in medium-speed motion drag chains.
